Applications 应用
HZ-FF Series couplings are widely used in the public utility market where hydraulic oil spillage
can constitute a serious safety hazard, particularly in overhead bucket hoists that are used
for maintenance of high-voltage power transmission lines. These couplings are also used for
quick change of hydraulic Tools in construction, railway maintenance and mining industries.
The ease of cleaning makeshift themideal for use in these types of hostile environments.
HZ-FF系列接头广泛用于以下公用设施: 液压油泄漏会构成严重的安全险情，尤其对用于高
压电源输送线维护的架空斗式起重机。这类接头还用于建筑、铁路维护及矿业中的液压机
具之快速切换，易于清理使之能理想地用于这类特殊环境
|
Features 特征
New valve design, it cans resistance damage from high flow and the pressure of impulse that
providing advanced performance.
Sleeve locking mechanism is engaged by rotating sleeve after connection. It prevents accidental
disconnection when coupling is dragged along the ground.
Sleeve mechanism is designed to help prevent dirt from entering the internal mechanism and
thus causing faulty operation when connecting or disconnecting. The sleeve covers the retaining
ring and also incorpor ates a dust seal in the springarea.
Hardened nipples and sleeves and solid barstock construction make for a quality coupling with
maximum resistance to damage from hydraulic and mechanical shock.
This Anti-Blowout Nitrile/PTFE bonded seal is designed to prevent blow-out or damage during
severe service conditions.
Durable ball-locking mechanism assures reliable connection every time. A largenumber of
locking balls distributes and work load evenly while providing alignmentand swiveling action
to reduce hose torque and prolong hose life. CAUTION: Theseproducts are not to be used as
swivels; rotation under pressure will result in excessive and premature wear.
HZ-FF Series couplings employ flush valving when connecting or disco nnecting. This means
that the valves are mated together so that only small amounts of fluid can be lost during
disconnection or air inclusion during reconnection.
New chrome plating treatment provides advanced anti-rust performance.
HZ-FF Series conforms to the standard of ISO16028.
Compatible with PARKER FE, FF Series, STUCCHI A8008 Series, AEROQUIP FD89 Series and
HANSEN QA2900 Series.
新型阀的设计，能抵抗高速流体与脉冲压力的冲击，提供更高的性能。
套筒锁紧机构通过连接后旋转套筒而啮合。可防止接头在地上拖动时意外断开。
套锁机构的设计有助于防止杂物进入内部机构从而在连接或断开时引起误操作。套筒覆盖挡圈
并且在弹簧区域包含了防尘密封件。
经过淬火处理的公插头和套筒以及实心棒料结构造就优质接头，它可最大限度的抵抗由于液压
和机械冲击而造成的损坏。
这种抗爆裂BFT密封圈设计用于防止在危险工作状况下出现爆裂或损坏。
耐用球锁机构保证每次都能可靠连接。更多数量的锁定钢球均匀分配工作负载，同时提供对中
及旋转动作从而减小软管扭曲并延长软管使用期。
警告：这类产品不能用作旋转接头，在压力下旋转会导致过度和过早磨损。
HZ-FF系列接头在连接及断开时使用平齐阀机构操作。这意味着阀之间的接合能使断开时只损失少
量流体，或在重新连接时只混入少量空气。
采用新工艺环保镀锌，提供更高的防锈性能。
HZ-FF接头符合ISO16028标准D
并与下列产品互换: 美国派克(PARKER) FE系列，FF系列、意大利意图奇(STUCCHI) A8008系
列、美国爱力克(AEROQUIP) FD89系列、美国汉森(HANSEN) QA2900系列。
|
